All imported components and heaters are made of stainless steel
The shrinkage temperature can be controlled at will, and the maximum temperature can reach 250 centigrade
The conveying speed is stepless speed regulation by the electronic governor
Only heating the bottle neck part will not affect the quality of the object in the bottle because of the high temperature
The whole machine adopts high strength carbon steel, and the surface is treated
Two unit small power wind motors, turbo wind, will not cause label displacement and deformation,
Only through simple setting and adjustment, can be adapted to various specifications of the bottle type
Only for local heating of the product, maximum thermal energy savings
This machine can be produced by single machine and can also be connected with production line
Scope of application
This series adopts hot air circulation shrink, mainly for the bottle, pot, barrel products such as labels shrink
Applicable to food, beverage, medicine, cosmetics, pesticide and other industries of glass bottles, plastic bottles, paper cups and other containers, sets of labeled bottle or cup body label heat shrinkage
|
Machine Size L×W×H(mm) |
1543×494×1467 |
|
Heating furnace size L×W×H(mm) |
1000×150×400 |
|
Max Pack Object Diameter ×H(mm) |
φ120×400 |
|
Speed （piece /hour ） |
8000-12000 |
|
Net Weight (kg) |
130 |
|
Power (kw) |
3.5 |
|
Voltage |
3PH 380V 50Hz |
|
Applicable Film |
POF/PVC/PE |
