1, the use of electronic tube trigger, filament voltage stability, to achieve constant voltage, high precision stepless pressure regulation
2, the output power is strong, even if the mouth is not smooth or stained with water, oil, powder or packaging materials, still can be effectively sealed.
3, automatic overload and cooling protection, using set operation, automatic, wide area load matching.
4 、 international advanced sealing coil design. Aluminum foil inspection and automatic alarm (pick bottles without foil according to user needs).
5 、 adjustable sealing head support and stainless steel railing support, can effectively expand the scope of use of bottles.
6 、 the use of high-strength plastic chain plate transmission, the shell all stainless steel materials, suitable for use in different environments, can work independently, more in line with the packaging line.
The product can effectively
guarantee the sealing performance, and has the efficacy of anti-theft,
moisture-proof and prolonging the storage period of the product sealed by the
product. Sealing speed, easy to control, stepless adjustment. Minimum energy
consumption and least impact on packaging material properties.
Name CFL-4
Sealing speed 1~4.5M/MIN
Bottle size diameter of 15~
with 50MM
Power 220V/50Hz
Power 2.5KW
The anode current rating is
400MA
Optimum ratio of positive
grid current to 5:1-10:1
Filament rated voltage 10V
Outline size (host)
500x400x1240mmm
Overall dimensions (conveyor
belts) 1510x270x840mmm
Weight 150kg
